PC board apci-1016

APCI-1016 - DAQ PCI-Karte - Digitale Eingänge

Die PCI-Karte mit 16 digitalen Eingängen APCI-1016 verfügt über 16 digitale 24-V Eingänge. Alle Eingänge sind gefiltert und gegen Verpolung geschützt. Die Karte ist mit einer galvanischen Trennung bis 1000 V ausgestattet. Sie kann für die industrielle E/A-Steuerung, Signalschaltung, als Interface zu elektromechanischen Relais, für automatische Testeinrichtungen, zur EIN/AUS-Überwachung von Motoren, Lampen etc. und als Interface zu Maschinen etc. eingesetzt werden.

Angebot anfordern



Kategorie:

Beschreibung

Technische Merkmale

  • 16 optoisolierte Eingänge, 24 V

Sicherheitsmerkmale

  • Galvanische Trennung 1000 V
  • Kriechstrecke IEC 61010-1
  • Verpolungsschutz
  • Alle Eingänge sind gefiltert
  • Schutz gegen schnelle Transienten (Burst), Überspannung, elektrostatische Entladung und hochfrequente Störeinstrahlung

Anwendungen

  • Industrielle E/A-Steuerung
  • Signalschaltung
  • Interface zu elektromechanischen Relais
  • Automatische Testeinrichtungen
  • EIN/AUS Überwachung von Motoren, Lampen...
  • Interface zu Maschinen

Softwaretreiber

A CD-ROM with the following software and programming samples is supplied with the board.

Standardtreiber für:

Standardtreiber und Applikationsbeispiele auf Anfrage:

  • Linux
  • Windows (32/64)
  • Real-time with Linux (i.e Xenomai) and Windows (i.e RTX) on request

Auf Anfrage:

Weitere Betriebssysteme, Compiler und Samples. Driver download: www.addi-data.com/downloads
