Need advice for choosing the right Fieldbus DAQ System?
With a wide range of Fieldbus DAQ Systems available, identifying the best fit for your application can be complex. Our experts support you in selecting the most suitable solution, based on your technical requirements and industrial environment.
|
|
MSX-E3011 |
16 analog inputs - Sampling rate: 100 kHz - Input resolution: 16 bits |
|
|
MSX-E3021 |
16 analog inputs - Sampling rate: 100 kHz - Input resolution: 16 bits 4 Go build-in flash memory |
|
|
MSX-E3027 |
16 analog inputs - Sampling rate: 100 kHz - Input resolution: 16 bits 4 Go build-in flash memory IP67 stainless steel housing |
|
|
MSX-E3121 |
6 analog inputs - Sampling rate: 100 kHz - Input resolution: 24 bits 4 analog outputs - Settling time: / - Output resolution: 16 bits 32 digital I/O 24 V |
|
|
MSX-E3122 |
6 analog inputs - Sampling rate: 100 kHz - Input resolution: 24 bits 4 analog outputs - Settling time: / - Output resolution: 16 bits 64 digital I/O 24 V |
|
|
MSX-E3511 |
8 analog outputs - Settling time: 25 µs - Output resolution: 16 bits |
| TEMPERATURE MEASUREMENT | ||
|
|
MSX-E3211 |
16 analog temperature inputs - Sampling rate: sensor dependant - Input resolution: 24 bits - Integrated cold junction compensation - Current sources for RTD sensors |
| PRESSURE MEASUREMENT | ||
|
|
MSX-E3311 |
16 analog pressure inputs - Sampling rate: sensor dependant - Input resolution: 24 bits - Integrated power supply for strain gauges |
| VIBRATION MEASUREMENT | ||
|
|
MSX-E3601 |
8 analog vibration inputs - Sampling rate: sensor dependant - Input resolution: 24 bits - Integrated power supply for IEPE sensors |
 |
MSX-EC-3000 |
16 analog inputs - Sampling rate: 5 kHz - Input resolution: 16 bits 8 digital I/O 24 V |
