APCI-2016

The PCI board with 16 digital outputs APCI-2016 has 16 digital outputs, 24 V. It is especially suited for industrial I/O control, signal switching, as interface to electromechanical relays, for automated test devices, for ON/OFF monitoring of motors, lights etc. and as interface to machines in the harsh industrial environment.



Description

Features

  • 16 optically isolated digital outputs, 10 V to 36 V
  • Output current per channel 500 mA
  • Watchdog for resetting the outputs to “0“
  • One ground line for all outputs
  • At Power-On, the outputs are reset to “0”

Safety features

  • Optical isolation 1000 V
  • Creeping distance IEC 61010-1
  • Protection against fast transients (burst), overvoltage, electrostatic discharge and high-frequency EMI
  • Short-circuit current for 16 outputs ~ 3 A typ.
  • Short-circuit current per output ~ 1.5 A typ.
  • Self-resetting fuse (electronic fuse)
  • Overtemperature and overvoltage protection
  • 24 V power outputs with protection diodes and filters
  • Output capacitors against electromagnetic emissions
  • External 24 V voltage supply screened and filtered
  • Shutdown logic, when the external supply voltage drops below 5 V
  • Diagnostic function for detecting short-circuits and overtemperature

Applications

  • Control of industrial PC-based processes
  • Signal switching
  • Interface to electromechanical relays
  • Automatic test equipment
  • ON/OFF monitoring of motors, lights…
  • Watchdog timer
  • Machine interfacing, …

Software drivers

A CD-ROM with the following software and programming samples is supplied with the board.

Standard drivers for:

  • Linux
  • 32-bit drivers for Windows 8 / 7 / Vista / XP / 2000
  • Signed 64-bit drivers for Windows 8 / 7 / XP
  • Real-time use with Linux and Windows on request

Drivers and samples for the following compilers and software packages:

  • .NET
  • Microsoft VC++ • Borland C++
  • Visual Basic • Delphi
  • LabVIEW • LabWindows/CVI • DIAdem

ADDIPACK functions:

  • Digital output • Watchdog

On request:

Further operating systems, compilers and samples. Driver download: www.addi-data.com/downloads
