APCIe-2032-5 – DAQ PCIe Card – Digital Outputs

The PCI-Express card with 32 digital outputs APCIe-2032-5 has 32 digital outputs, 5 V and a programmable watchdog. It is especially suited for applications like signal switching, ON/OFF monitoring of motors, lights etc., als interface to electromechanical relays, for automated test systems or as interface to machines in the harsh industrial environment.

Category: DAQ cards Digital outputs

Description

Features

Connector and software compatible to the digital output board APCI-2023 for the PCI bus
32 digital outputs, 5 V version, optically isolated
Output current per channel: 500 mA
Voltage range: 10 V to 36 V
Diagnostic report, through status register at shortcircuits, overtemperature, voltage drop or watchdog
Programmable watchdog for resetting the outputs to “0“, function release through software
Interrupt triggered through error
At Power-On the outputs are reset to “0“

Safety features

Optical isolation 1000 V
Creeping distance IEC 61010-1
Protection against fast transients (burst), overvoltage, electrostatic discharge and high-frequency EMI
Maximum output current for 32 outputs 6 A typ. (2 x 3 A)
24 V power outputs with protection diodes and filters
Self-resetting fuse (electronic fuse)
Short-circuit current per output 1.5 A typ.
Output capacitors against electromagnetic emissions
Fast demagnetisation in case of inductive loads
External 24 V voltage supply screened and fi ltered
Shutdown logic: If the external 24 V voltage drops below 5 V, then the outputs are switched off.
